SECTION 7: ILLUSTRATED PARTS LIST
7 - 20 090189-OP_r0 (JUNE-2022)
VANAIR MANUFACTURING, INC.
(844) VAN-SERV • www.vanair.com
Cap•Start Hydraulic-Driven
12V/24V • Battery Starter • Charger
TOP VIEW
7
1
5
6
2
3
4
7.9 DECAL IDENTIFICATION/LOCATION - 1 OF 2
WARNING
DO NOT REMOVE OR COVER ANY SAFE-
TY DECAL. Replace any safety decal that
becomes damaged or illegible.
ITEM DESCRIPTION PART NUMBER QTY
1 DECAL, WARN ING ELECTRIC TAMPER 271510 1
2 DECAL, WARN QUALIFIED PERSONNEL 271535 1
3 DECAL, WARN-CANCER, REPRO, HARM 279065 1
4 DECAL, READ MANUAL 272424 1
5 DECAL, WARNING FAN GUARD 264383 1
6 DECAL, WARNING HIGH PRESSURE 264380 1
7 DECAL, CAUTION AUTO-START 272041
1
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE MACHINE SERIAL NUMBER.
6110154ID_r1_1of2
