SECTION 7: ILLUSTRATED PARTS LIST
090189-OP_r0 (JUNE-2022) 7 - 7
VANAIR MANUFACTURING, INC.
(844) VAN-SERV • www.vanair.com
Cap•Start Hydraulic-Driven
12V/24V • Battery Starter • Charger
7.2 FINISHED ASSEMBLY - 2 OF 3
ITEM DESCRIPTION PART
NUMBER
QTY ITEM DESCRIPTION PART
NUMBER
QTY
1 TRIM-LOK, 1/16 GROOVE NEOPRENE PUSH ON 265257 3.5” 17 CAPSCREW, HEX GR5 1/4-20 x 0.75 829104-075 2
2 SCREW, TRUSS #4-40 X 1/2 271839 4 18 CAPSCREW, HEX GR5 5/16-18 x 0.75 829105-075 8
3 NUT, HEX LOCKING #4-40 UNC 271840 4 19 CAPSCREW, HEX GR8 3/8-16 x 0.75 829406-075 2
4 SENSOR, HALL EFFECT 500 AMP 275718 1 20 WASHER, FLAT 5/16 838205-071 6
5 CABLE, M12 MALE/FEMALE PATCH 90/STRAIGHT
2 FT
277892-02 1 21 WASHER, FLAT 3/8 838206-071 2
6 PANEL, MIDDLE CS3KH 281332 1 22 WASHER, LOCK 1/4 838504-062 6
7 HARNESS,CS3KH POWER CONNECTOR A 282040 1 23 WASHER, LOCK 5/16 838505-078 10
8 BELT, DRIVE 3VX210 282389 3 24 WASHER, LOCK 7/16 838507-109 1
9 TUBE, MOTOR RETURN CS3KH 282391 1 25 BULKHEAD, MJIC x MJIC #4 862104-025 1
10 TUBE, MOTOR PRESSURE CS3KH 282392 1 26 ID, CANOPY & PARTS CS3KH 6030207ID 1
11 CABLE, OUTPUT CS3KH 282418 1 27 ID, ASSY ALTERNATOR 240A CS3KH 6050122ID 1
12 TUBE, CASE DRAIN CS3KH 282598 1 28 ID, ELEC ASSY, FRAME, CAPACITOR
AND RELAY
6060337ID 1
13 BRACKET, CASE DRAIN AND CONNECTOR CS3KH 282599 1 29 ASSY, CONTROL MODULE CS3KH 6060352ID 1
14 NUT, HEX 5/16-18 825205-273 2 30 ID, ASSY MOTOR CS3KH 6100281ID 1
15 CAPSCREW, S.H. 1/4-20 x 1 3/4 828304-175 2 31 DECAL GROUP CAPSTART 3000,
HYDRAULIC
6110154ID 1
16 CAPSCREW, HEX GR5 1/4-20 x 1/2 829104-050 2 32 ID, MANIFOLD ASSY, CS3KH 6120460ID 1
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE MACHINE SERIAL NUMBER.
