SECTION 7: ILLUSTRATED PARTS LIST
090189-OP_r0 (JUNE-2022) 7 - 11
VANAIR MANUFACTURING, INC.
(844) VAN-SERV • www.vanair.com
Cap•Start Hydraulic-Driven
12V/24V • Battery Starter • Charger
7.3 ELECTRICAL ASSEMBY, FRAME, CAPACITOR AND RELAY - 2 OF 2
ITEM DESCRIPTION PART NUMBER QTY
1 ULTRACAPACITOR, 65.52kJ 12/24V 277956 2
2 DECAL,VSC LS MTRON 278446 2
3 BAR, COPPER BUS 280201 4
4 RELAY,500 AMP 12V COIL w/STUDS N.O. 280203 5
5 BASE,CAPSTART3000 HYDRAULIC 281312 1
6 HARNESS,CS3KH CONTROLS CONNECTOR B 282039 1
7 KIT,CABLE CAPSTART 3000 HYDRAULIC 282577 1
8 CAPSCREW, HEX GR5 1/4-20 x 0.75 829104-075 8
9 CAPSCREW, HEX GR5 5/16-18 x 0.75 829105-075 4
10 SCREW,MACHINE 10-32 X 1.0 831702-100 10
11 WASHER, FLAT 5/16 838205-071 4
12 WASHER, LOCK 1/4 838504-062 8
13 WASHER, LOCK 5/16 838505-078 4
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE MACHINE SERIAL NUMBER.
