SECTION 7: ILLUSTRATED PARTS LIST
090189-OP_r0 (JUNE-2022) 7 - 13
VANAIR MANUFACTURING, INC.
(844) VAN-SERV • www.vanair.com
Cap•Start Hydraulic-Driven
12V/24V • Battery Starter • Charger
7.4 ALTERNATOR ASSEMBLY
ITEM DESCRIPTION PART NUMBER QTY
1 ALTERNATOR, 240A PAD MOUNT, MULIT-VOLT 276942 1
2 SHEAVE, 3Vx3, 3.65IN DIA 277163 1
3 FAN, 7IN PULL MECH 280908 1
4 WASHER, FAN MOUNTING 280975 1
5 BRACKET, ALTERNATOR SLIDE CS3KH 281320 1
6 NUT, HEX LOCKING 3/8-16 825506-198 4
7 CAPSCREW, HEX HD GR 8 1-8 UNC-2A x 4.00 LG 829406-400 4
8 SCREW, SER WASH #10-24 x 0.5 829702-050 4
9 WASHER, FLAT 3/8” 838206-071 4
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE MACHINE SERIAL NUMBER.
