SECTION 7: ILLUSTRATED PARTS LIST
090189-OP_r0 (JUNE-2022) 7 - 15
VANAIR MANUFACTURING, INC.
(844) VAN-SERV • www.vanair.com
Cap•Start Hydraulic-Driven
12V/24V • Battery Starter • Charger
7.5 MOTOR ASSEMBLY
ITEM DESCRIPTION PART NUMBER QTY
1 CONNECTOR, #10 MSAE x #8 MJIC 260387-108 1
2 CONNECTOR,O-RING 3/4 x 3/4 JIC 260387-112 1
3 SHEAVE, GATES #QD 3/3V 6.00 262812 1
4 BUSHING, SPLIT TAPER SDS 3/4 267308 1
5 BOLT, TAP 3/8-16 x 2 270075 1
6 BRACKET, H YDRAULIC MOTOR 281319 1
7 MOTOR, HYDRAULIC 15CC 3/4” X 2” SHAFT REAR PORT PERMCO 284045 1
8 NUT, HEX 3/8-16 825206-337 3
9 CAPSCREW, HEX GR5 3/8-16 x 1.25 829106-125 2
10 WASHER, FLAT 5/16” x 0.875” 838206-071 2
11 WASHER, LOCK 3/8 838506-094 2
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE MACHINE SERIAL NUMBER.
