VarioCooking Center 211 - VCC 112 T, 112 L & 112, from index J

VCC 112T, 112L & 112, from index J
VCC 112T: Components and identication
Actuator and limit switch identication, VCC112T
Left
●M2Lefttiltingactuator
●PT1potentiometerformotorM2
●S10LeftAutoLiftuplimitswitch
Right
●M6Righttiltingactuator
●PT2potentiometerofmotorM6
●S10RightAutoliftuplimitswitch
Components
X.12
v03 • July-2016 • Hen
Motorisation Module
Line Units Serial number (starting from) Sw Revision
VCCM
VCCWE
112T, 112L E12VJ1505xxxxxxx, E13VJ1509xxxxxxx
TOUCH + TFT
+ A1 (MMi)
A2 (Main Board)
PT1 / PT2
M2 / M6
A4 (I/O Board)
A5 (X-Relay)
1
2
12VDC
