VarioCooking Center 211 - VCC 211;311, all indexes

VCC 211/311, all indexes
Components and identication
Actuator and limit switch identication
Fig.1
●M2Pantiltingactuator
●PT1PotentiometerformotorM2
●M3Lidtiltingactuator
●PT2potentiometerofmotorM3
●M4Lidlockactuator
●S6,S7limitswitchmotorM4
Components
X.24
v03 • July-2016 • Hen
Motorisation Module
Line Units Serial number (starting from) Sw Revision
VCCM
VCCWE
211, 311 E21xH1009xxxxxxx, E31xH1009xxxxxxx
TOUCH + TFT
+ A1 (MMi)
A2 (Main Board)
A5 (X-Relay)
PT1 / PT2
M2
T2
17-24VDC
