VarioCooking Center 211 - Page 175

Pressure circuit models 112+
List of components
Components
Function 112
Left
112
Right
Note
Pressure switch P Max
F7 F12 P Max = 200 mbar
if P > 200 mbar cut-off of the device
Pressure switch P Min.
F11 F13 P Min = 20 mbar
Pressure sensor
P1 P2 Output signal from 0 to 5 VDC
Decompression
solenoid valve
Y4 Y5 Solenoid valve normally open
Control box
solenoid valve
Y2 Maximum temperature of water 25°C
Pressure measuring nozzle
A
Cold water supply
B Maximum temperature of water 25°C
Control box
C
Flow
D Condensed steam
XI.05
v03 • July-2016 • Hen
Pressure Module
Line Units Serial number (starting from) Sw Revision
VCCM
VCCWE
112P E11PH1009xxxxxxx
