Pressure circuit models 211+ / 311+
List of components
List of components 211/311
Pressure switch P Max
F7 P Max = 200 mbar
If P > 200 mbar cut-off of the device
Pressure switch P Min.
F11 P Min = 20 mbar
if P > 25 mbar blocking of the unlocking of the cover
Pressure sensor
P1 Output signal from 0 to 5 VDC
Decompression
solenoid valve
Y4 Solenoid valve normally open
Control box
solenoid valve
Y2 Maximum temperature of water 25°C
Pressure measuring nozzle
A
Cold water supply
B Maximum temperature of water 25°C
Control box
C
Flow
D Condensed steam
XI.07
v03 • July-2016 • Hen
Pressure Module
Line Units Serial number (starting from) Sw Revision
VCCM
VCCWE
211P
311 P
E21PH1009xxxxxxx
E31PH1009xxxxxxx
