SD card
SD card or Main Board A2 exchange procedure
Exchange of the Main Board A2 (new),
SD card remains (already used).
A. Put the SD card into the new main board A2.
B. Fit the new A2 card in the unit with the power off.
C. It is preferable to connect a USB stick loaded
the latest version of software.
D. During power-up a special menu appears.
The technician must conrm that he wants
to copy the data from the SD card to the unit.
Press the button for 10 seconds:
E. Data is copied from the SD card to the Main
Board A2. The process is irreversible.
F. Wait for the main menu to appear.
The allocation and calibration of the heating
zones is now mandatory!
It is advisable to remove the USB stick
from the unit with the power off!
Exchange of the SD card (new), Main
Board A2 remains (already used).
A. With the unit off remove the old SD card and
install the new one.
B. It is preferable to connect a USB stick loaded
the latest version of software.
C. Turn the unit on and wait for the main menu
to appear.
D. The unit automatically copies the data from
the A2 card to the SD card. The process is
irreversible.
The allocation and calibration of the heating
zones is now mandatory!
It is advisable to remove the USB stick
from the unit with the power off!
v03 • July-2016 • Hen
VI.14
Control Module
Line Units Serial number (starting from) Sw Revision
VCCM
VCCWE
All ExxVH1009xxxxxxx 01-00-08
