VAT 613 Series

Series 613 INSTALLATION
984360EC Edition 12.08.2022 53/
149
Compressed Air
Pressure
10A40000 FLOAT RW NV mbar* Only for series 65.3
Compressed Air Error
Enable
10A90000
BOOL
RW
NV
Only for
series 65.3
Speed Mode 10990000 0: Low Speed
1: Mid Speed
2: High Speed
3: Undefined
4: IC Slow Pos/Slow Prs
5: IC Fast Pos/Slow Prs
6: IC Fast Pos/Fast Prs
Available speed Mode depends
on valve series
5.12.7.3 Position Control
Sub Group Parameter ID [hex] Data Type Acc NV Unit Min Max Description
Actual Position 11010000 FLOAT RO V [pos]* 0 100
Target Positon 11020000 FLOAT RW V [pos]* 0 100
Position Control
Speed
11030000
FLOAT
RW
NV
0.001
1
Speed valid in
Control Mode
= Position
1.0 equals to full speed
Ramp Enable 11620100 BOOL RW NV 0 1 Activate/Deactivate position target ramp.
Time 11620200 FLOAT RW NV sec 0 1000000
Slope
11620300
FLOAT
RW
NV
mbar*/sec
0
100000000
Mode
11620400
UINT8
RW
NV
0
1
0
:Use Ramp
Time
1:Use Ramp Slope
Type 11620500 UINT8 RW NV 0 2 0:Linear
1:Logarithmic
2:Exponential
