5.12.7.4 Pressure Control
Sub Group Parameter ID [hex] Data Type Acc NV Unit Min Max Description
Target Pressure
Used
07030000 FLOAT RO V mbar* 0 SFS This value is set as pressure controller input. It
differs to the Target Pressure if a pressure ramp
is used.
Pressure Control
Speed
07050000
FLOAT
RW
NV**
0.001
1
Speed valid in
Control Mode
= Pressure
1.0 equals to full speed
Controller Selector 07100000 UINT8 RW NV** 1 4 Active Controller in Control Mode = Pressure
1:Controller 1
2:Controller 2
3:Controller 3
4:Controller 4
Controller 1
xx = 11
Controller 2
xx = 12
Controller 3
xx = 13
Controller 4
xx = 14
Control Algorithm
07xx0100
UINT8
RW
NV**
0
2
0
:Adaptive
1:PI
2:Soft Pump
Adaptive
Setting
Gain Factor 07xx0203 FLOAT RW NV** 0.000
1
100
Sensor Delay
07xx0204
FLOAT
RW
NV**
sec
0
1
Learn Data Selection 07xx0205 FLOAT RW NV** 0: Learn Bank 1
1: Learn Bank 2
2: Learn Bank 3
3: Learn Bank 4
PI
Soft Pump
Settings
P-Gain 07xx0201 FLOAT RW NV** 0.001 100 Proportional Gain
I-Gain 07xx0202 FLOAT RW NV** 0 100 Integral Gain
Control Direction 07xx0206 BOOL RW NV** 0 1 0: Downstream
1: Upstream (not supported by Adaptive Control
Algorithm)
Pressure Scaler 07xx0223 UINT8 RW NV** 0 1 Defines the used pressure scaling inside the
pressure controller.
0: Linear
1: Logarithmic
Ramp Enable 07xx0301 BOOL RW NV** 0 1 Activate/Deactivate pressure target ramp.
The effective target pressure can be read in
Target Pressure Used
Time
07xx0302
FLOAT
RW
NV**
sec
0
1000000
Target reach time
Slope 07xx0303 FLOAT RW NV** mbar*/sec 0 1000000
Mode 07xx0304 UINT8 RW NV** 0 1 0:Use Ramp Time
1:Use Ramp Slope
Type
07xx0306
UINT8
RW
NV**
0
1
0
:Linear
1:Logarithmic
2:Exponential
Start Value 07xx0305 UINT8 RW NV** 0 1 0:Previous Ramp Value
1:Actual Pressure Value
General
Settings
Store Control
Parameter Volatile
07301100 BOOL RW NV 0 1 0: Store in NV Memory
1: Do Not Store in NV Memory
Control Position
Restriction
Enable
07301201
BOOL
RW
NV
Limit the movement during pressure control
Minimum Control
Position
07301202
FLOAT
RW
NV
[pos]*
0
100
Maximum Control
Position
07301203
FLOAT
RW
NV
[pos]*
0
100
Automated
Controller
Selector
Enable 07301701 BOOL RW NV 0 1
Mode 07301702 UINT8 RW NV 0: Threshold
1: Pressure Direction
Controller Selector
Bitmap
07301703 UINT8 RW NV Selection of those controllers that are used
Threshold Condition
07301710
UINT8
RW
NV
0
: Lower Or Equal
1: Equal
Controller 1
Threshold
07301704 FLOAT RW NV mbar* Used if Mode = Threshold
Controller 2
Threshold
07301705 FLOAT RW NV mbar* Used if Mode = Threshold
Controller 3
Threshold
07301706
FLOAT
RW
NV
mbar*
Used if Mode =
Threshold
Controller 4
Threshold
07301707 FLOAT RW NV mbar* Used if Mode = Threshold
Controller Pressure
Rising
07301720 UINT8 RW NV 1 4 Used if Mode = Pressure Direction
Controller Pressure
Falling
07301721
UINT8
RW
NV
1
4
Used if Mode =
Pressure Direction
