Series 613 INSTALLATION
984360EC Edition 12.08.2022 59/
149
5.12.7.7 Power Connector IO
Sub Group Parameter ID [hex] Data Type Acc NV Unit Min Max Description
Digital
Input 1
Enable 37010100 BOOL RW NV 0 1 Logic IO available on the valve power connector
State
37010200
BOOL
RO
V
0
1
Functionality
37010300
SINT8
RW
NV
0
2
0
:Interlock Open
1:Interlock Close
2:Hold
Inverted 37010400 BOOL RW NV 0 1
Digital
Input 2
Enable 37020100 BOOL RW NV 0 1 Logic IO available on the valve power connector
State 37020200 BOOL RO V 0 1
Functionality
37020300
SINT8
RW
NV
0
2
0
:Interlock Open
1:Interlock Close
2:Hold
Inverted 37020400 BOOL RW NV 0 1
Digital
Output 1
Enable 37030100 BOOL RW NV 0 1 Logic IO available on the valve power connector
State 37030200 BOOL RO V 0 1
Functionality
37030300
SINT8
RW
NV
0
2
0
:Open
1:Close
2:Hold
Inverted 37030400 BOOL RW NV 0 1
Digital
Output 2
Enable 37040100 BOOL RW NV 0 1 Logic IO available on the valve power connector
State 37040200 BOOL RO V 0 1
Functionality
37040300
SINT8
RW
NV
0
2
0
:Open
1:Close
2:Hold
Inverted 37040400 BOOL RW NV 0 1
Drive Power Enable 37500000 BOOL RO V 0 1 Drive/Motor power can be enabled/disabled by a
power connector pin (safety feature). This
parameter shows if the drive/motor power is
enabled. Refer to manual for further information.
5.12.7.8 Power Fail Option
Only if a Power Fail Option is installed.
Sub Group Parameter ID [hex] Data Type Acc NV Unit Min Max Description
Enable
22010000
BOOL
RW
NV
Only valid if a Power Fail Option is available
State
22020000
SINT8
RO
V
0
3
0
:Battery is Charging
1:Ready To Use
2:Active
3:Failure
Functionality 22030000 SINT8 RW NV 0 1 0:Open
1:Close
Delay
22040000
FLOAT
RW
NV
0.0
2.0
Battery
Voltage
22050000
FLOAT
RO
V
Power Fail Cycles
22060000
UINT16
RW
NV
