VAT 613 Series

INSTALLATION Series
613
58/149 Edition 12.08.2022
984360EC
Sub Group Parameter ID [hex] Data Type Acc NV Unit Min Max Description
Scaling
Position
Position Unit
A1120101
SINT16
RW
NV
0
7
0
:0
-
1
1:0 - 10
2:0 - 90
3:0 - 100
4:0 - 1000
5:0 - 10000
6:0 - 100000
7:User specific (Range is defined by
Value Closest
Position and Value Open Position)
Value Closest Position
A1120102
FLOAT
RW
NV
Defines the User Specific range
Value Open
Position
A1120103
FLOAT
RW
NV
Pressure
Pressure Unit
A1120201
SINT16
RW
NV
0
7
0
:Pa
1:kPA
2:bar
3:mbar
4:Torr
5:mTorr
6:psi
7:User specific (Range is defined by Value
Pressure 0 and Value Pressure Sensor Full
Scale)
Value Pressure 0
A1120202
FLOAT
RW
NV
Defines the User Specific range
Value Pressure Sensor
Full Scale
A1120203
FLOAT
RW
NV
Compound
Commands
1[20] A10A0100 UINT32 RW NV
Parameter compilation for set and/or get several
Parameters with one command
Array of max 20 Parameter IDs
2[20] A10A0101 UINT32 RW NV
3[20] A10A0102 UINT32 RW NV
4[20] A10A0103 UINT32 RW NV
Input
Output
Digital
Input 1
Enable A1200101 BOOL RW NV 0 1
State A1200102 BOOL RO V 0 1
Functionality A1200103 SINT8 RW NV 0 2 0:Interlock Open
1:Interlock Close
2:Hold
Inverted
A1200104
BOOL
RW
NV
0
1
Digital
Input 2
Enable
A1200201
BOOL
RW
NV
0
1
State A1200202 BOOL RO V 0 1
Functionality A1200203 SINT8 RW NV 0 2 0:Interlock Open
1:Interlock Close
2:Hold
Inverted
A1200204
BOOL
RW
NV
0
1
Digital
Output 1
Enable
A1200301
BOOL
RW
NV
0
1
State
A1200302
BOOL
RO
V
0
1
Functionality A1200303 SINT8 RW NV 0 2 0:Open
1:Close
2:Hold
Inverted A1200304 BOOL RW NV 0 1
Digital
Output 2
Enable
A1200401
BOOL
RW
NV
0
1
State
A1200402
BOOL
RO
V
0
1
Functionality
A1200403
SINT8
RW
NV
0
2
0
:Open
1:Close
2:Hold
Inverted A1200404 BOOL RW NV 0 1
Analog Output
Pressure
Value A1200501 FLOAT RO V Volt
0.0 10.0
User Factor A1200502 FLOAT RW NV 0.1 10.0
User Offset
A1200503
FLOAT
RW
NV
-
10.0
10.0
Analog Output
Position
Value
A1200601
FLOAT
RO
V
V
olt
0.0 10.0
User Factor
A1200602
FLOAT
RW
NV
0.1
10.0
User Offset
A1200603
FLOAT
RW
NV
-
10.0
10.0
