VAT 613 Series

Series 613 INSTALLATION
984360EC Edition 12.08.2022 57/
149
5.12.7.6 Interface RS232/RS485
Sub Group Parameter ID [hex] Data Type Acc NV Unit Min Max Description
Operation Mode A1010000 SINT8 RW NV 0 2 0:RS232
1:RS485
2:Service Interface Over RS232
Settings Baud Rate A1110100 SINT8 RW NV 0 7 0:1200
1:2400
2:4800
3:9600
4:19200
5:38400
6:57600
7:115200
Data Bit Length A1110200 SINT8 RW NV 0 1 0:7
1:8
Stop Bit
A1110300
SINT8
RW
NV
0
1
0
:1
1:2
Parity Bit A1110400 SINT8 RW NV 0 2 0:None
1:Even
2:Odd
Topology
A1110800
SINT8
RW
NV
0
1
Only used
if
Operation Mode
=
RS485
0:Full Duplex
1:Half Duplex
Network A1110900 SINT8 RW NV 0 1 Only used if Operation Mode = RS485
0:Multiple Devices
1:Point to Point
Address
A1110A00
UINT8
RW
NV
0
255
Only used if
Operation Mode
= RS485
Command Set
A1110500
SINT8
RW
NV
0
2
0
:IC
1:PM
2:PM V2
3
: Tylan
4: Tylan Type 1
5: Tylan Type 2
Command Termination A1110B00 SINT8 RW NV 0 2 0: Carriage Return + Line
Feed
1: Line Feed
2: Carriage Return
R A Answer Only for Command Set = IC,PM, PMV2
0: Standard
1: i:76
Second Answer
Only for
Command Set
= PM, PMV2
0:Off
1:Pos/Prs
2:Pos
Learn Answer Only for Command Set = PM, PMV2
0:Immediatelly
1:Learn End
Command t Mode
Only for
Command Set
= PM, PMV2
0:Without Ramp Time
1:With Ramp Time
Tylan M1 Only for Command Set = Tylan, Tylan Type 2
0:None
1:Gain Factor/P-Gain
Tylan X1
Only for
Command Set
= Tylan, Tylan Type 2
0:None
1:Ramp Time/I-Gain
Tylan J3 Only for Command Set = Tylan, Tylan Type 2
0:None
1:Restart
Tylan V
Only for
Command Set
= Tylan Type 1, Type 2
0:None
1:Pressure Control Selector
Compound
Commands
1[20] A10A0100 UINT32 RW NV Parameter compilation for set and/or get several
Parameters with one command
Array of 20 Parameters
2[20] A10A0101 UINT32 RW NV
3[20]
A10A0102
UINT32
RW
NV
4[20]
A10A0103
UINT32
RW
NV
