Series 613 INSTALLATION
984360EC Edition 12.08.2022 61/
149
System
Set
Resp
Get
Resp
Data
Set, Get Resp
Description
i:76 i:76 aaaaaa
bbbbbbbbcde
Compound
a
Pressure
b Position
c
Access Mode:
0=Local, 1=Remote, 2=Locked
d Control Mode: 0=Init,1=Homing,2=Position,3=Close,4=Open,5=Pressure
Control,6=Hold,7=Learn,8=Interlock Open,9=Interlock Close,12=Power
Failure,13=Safety,14=Error
e Warning Present: (in i:51 or i:52) 0=no, 1=yes
s:04 s:04 i:04 i:04 abcdefgh Valve Configuration
a
Homing End Position:
0=Close, 1=Open
b
Power Failure Position:
0=Close, 1=Open
c
External Isolation Valve Enable:
0=no, 1=yes
d
Control Stroke Limitation Enable:
0=no, 1=yes
e
Network Failure Position
f Cluster Valve Offline
g
Homing Start:
0=Not Isolated or Move Command, 1=c:4303 Command,
2=Open Command, 3=Move Command, 1=At Power Up
h
Reserved
i:50 i:50 aaa Fatal Error Number:
20=Limit Stop Not Detected, 21=Blocked, 22=Blocked, 40=Motor Driver
c:53 c:53
i:51
i:53
i:51
i:53
abcdefgh Warnings 1
a
Service Request
b Learn Data Warning
c
PFO not ready
d
Compressed Air Failure
e Sensor Ratio
f
External
Isolation Valve Warning
g Cluster Slave Offline
h
Network Failure
i:53 = nonvolatile, c :5300 = reset
c:54 c:54
i:52
i:54
i:52
i:54
abcdefgh
Warnings 2
a
Rom Memory
b
Interface
c Sensor ADC
d
Interface ADC
e Reserved
f
Sensor value not valid
g Cluster Slave Offline
h
Network Failure
i:54 = nonvolatile, c :5400 = reset
c:20 c:20 i:70 i:70 aaaaaaaaaa Counter Control Cycles c:2000 = reset
c:21
c:21
i:71
i:71
aaaaaaaaaa
Counter Isolation Cycles
c:2100 = reset
c:22 c:22 i:72 i:72 aaaaaaaaaa Counter Power Up c:2200 = reset
c:10
c:10
aa
Power Failure Option Off:
0=Off (volatile), 1=On
c:82
c:82
aa
Reset:
1=Reset
