Pressure Control
Set
Resp
Get
Resp
Data
Set, Get Resp
Description
S: S: i:38 i:38 aaaaaaaa Pressure Control, a Target Pressure
H:
H:
Hold
K:
K:
Pressure Control Mode (Release Hold)
s:02
s:02a
s:02 i:02
i:02a
i:02 abcdeeff Pressure Control Setup
a
Controller:
0=Adaptive,1=PI Downstream,2=PI Upstream,3=Softpump
b Gain Factor (Adaptive)
0=0.1,1=0.13,2=0.18,3=0.23,4=0.32,5=0.42,6=0.56,7=0.75,8=1.0,9=1.33,A=1.78,B=2.37,
C=3.16,D=4.22,E=5.62,F=7.5,G=0.0001,H=0.0003,I=0.001,J=0.003,K=0.01,L=0.02,M=0.05
c Sensor Delay (Adaptive)
0=0,1=0.02,2=0.04,3=0.06,4=0.08,5=0.1,6=0.15,7=0.2,
8=0.25,9=0.3,A=0.35,B=0.4,C=0.5,D=0.6,E=0.8,F=1.0 sec
d Ramp Time
0=0.0,1=0.5,2=1.0,3=1.5,4=2.0,5=2.5,6=3.0,7=3.5,8=4.0,9=4.5,A=5.0 sec
e P-Gain (PI and Softpump)
0=0.001,1=0.0013,2=0.0018,3=0.0024,4=0.0032,5=0.0042,6=0.0056,
7=0.0075,8=0.01,9=0.013,10=0.018,11=0.024,12=0.032,13=0.042,
14=0.056,15=0.075,16=0.1,17=0.13,18=0.18,19=0.24,20=0.32,21=0.42,
22=0.56,23=0.75,24=1.0,25=1.3,26=1.8,27=2.4,28=3.2,29=4.2,30=5.6,
31=7.5,32=10,33=13,34=18,35=24,36=32,37=42,38=56,39=75,40=100
f
I
-
Gain (PI and Softpump):
Same values as P-Gain
s:02a00
s:02
i:02a00
i:02
value
Sensor Delay:
0.0 – 1.0sec, a = Controller: A,B,C,D
s:02a01
s:02
i:02a01
i:02
value
Ramp Time:
0.0 – 1000000.0sec, a = Controller: A,B,C,D
s:02a02
s:02
i:02a02
i:02
value
Ramp Mode:
0=constant time, 1=constant slope, a = Controller: A,B,C,D
s:02a03
s:02
i:02a03
i:02
value
Control Direction:
0=downstream, 1=upstream, a = Controller: A,B,C,D
s:02a04 s:02 i:02a04 i:02 value Gain Factor: 0.0001 – 7.5 (Control Algorithm = Adaptive)
P-Gain: 0.001 – 100.0 (Control Algorithm = PI or Softpump)
a = Controller: A,B,C,D
s:02a05
s:02
i:02a05
i:02
value
I
-
Gain:
0.001 – 100.0, a = Controller: A,B,C,D
s:02a06
s:02
i:02a06
i:02
value
Ramp Type:
0=linear, 1=logarithmic, 2=exponential, a = Controller: A,B,C,D
s:02a10 s:02 i:02a10 i:02 value Control Algorithm: 0=Adaptive, 1=PI, 2=Softpump, a = Controller: A,B,C,D
s:02a15
s:02
i:02a15
i:02
value
Learn Bank
, a = Controller: A,B,C,D
0=Learn Bank 1, 1=Learn Bank 2, 1=Learn Bank 3, 1=Learn Bank 4
s:02Z00
s:02
i:02Z00
i:02
value
Control Unit Selector:
0 .. 3
s:02Z10
s:02
i:02Z10
i:02
value
Save Volatile:
0=nonvolatile, 1=volatile
L: L: i:34 i:34 aaaaaaaa Learn , a Pressure Limit
i:32 i:32 abcdefgh Learn Status
a
Running
b
Data Not
Valid
c
Canceled:
1=By User, 2=By Learn Routine
d
Pressure At Open high or negative
e
Pressure At Close low
f
Pressure Decrease
g
Pressure Instable
h Reserved
s:08
s:08
i:08
i:08
aaaaaa
Learn Open Speed:
0 - 1000
i:36
i:36
abbbbbbb
Pressure
Control Status:
a
Adaptive control state:
0=roughly, 1=fine
b
Reserved
