VAT 613 Series - Page 77

Series 613 INSTALLATION
984360EC Edition 12.08.2022 77/
149
5.12.9.4 Digital Output
Pinout
Pin Default Function
8
OUTPUT 1
Open
9
OUTPUT 2
Closed
10
COMMON
Configuration
Parameter Description
Enable
1
enables the output
State
0
Not active
1 Active
Functionality
0
OPEN valve is fully open
1 CLOSE valve is fully closed (isolated if valve has an isolation function)
2
HOLD valve is in hold state
Inverted
Function
State
Output
0
Not Inverted
inactive 0 Off
active
1
On
1
Inverted
inactive 1 On
active
0
Off
5.12.9.5 Analog Output
Pinout
Pin Function Range
21
OUTPUT 1
Position 0V (Close) .. 10V (Open)
22
OUTPUT 2
Pressure
0 .. 10V SFS
20
COMMON
Configuration
Parameter Description
Value
Indicate the output voltage
User
Factor
Scaling of the Analog Output
Example: The desired output should be 1-9V
User Factor = 10V / ( MaxVolt – MinVolt ) = 10 / 8 = 1.25
User Offset = 1.0
User Offset
