Installation, Operating & Maintenance Instructions
Series 650 DN 100-250 (I.D. 4“ - 10”), CC-Link



VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel +41 81 771 61 61   Fax +41 81 771 48 30   CH@vatvalve.com www.vatvalve.com
280672EB
2010-12-15
50/94

Gasflow calculation for LEARN:


Do not apply a different gasflow for learn than determined below. Otherwise pressure control
performance may be insufficient.

1.  Calculate gasflow for learn. Choose the applicable formula depending on units you are familiar with.



            p
SFS
• C
min
• n

q
L
 =

q
L
  gasflow for learn [Pa m
3
/s]
p
SFS
  sensor full scale pressure [Pa]
C
min
min. controllable conductance of valve [l/s]
    (refer to «Technical data»)
n   number of valves in valve cluster, used during pressure control



            p
SFS
• C
min
• n

q
L
 =

q
L
  gasflow for learn [mbar l/s]
p
SFS
  sensor full scale pressure [mbar]
C
min
min. controllable conductance of valve [l/s]
    (refer to «Technical data»)
n   number of valves in valve cluster, used during pressure control


q
L
 = 39.4 • p
SFS
 • C
min
• n

q
L
  gasflow for learn [sccm]
p
SFS
  sensor full scale pressure [Torr]
C
min
min. controllable conductance of valve [l/s]
    (refer to «Technical data»)
n   number of valves in valve cluster, used during pressure control


3.7 Close valve

Local operation:
(‘Control View’, ‘Control Performance Analyzer’ or
‘Service Box 2‘)
Remote operation:
(Refer to chapter «OUTPUT Buffer» > «CONTROL
MODE SETPOINT» for details)
Push CLOSE button
1.  In «OUTPUT Buffer» > «CONTROL MODE
SETPOINT»
2.  Select the [Close] (value = 3)



3.8 Open valve

Local operation:
(‘Control View’, ‘Control Performance Analyzer’ or
‘Service Box 2‘)
Remote operation:
(Refer to chapter «OUTPUT Buffer» > «CONTROL
MODE SETPOINT» for details)
Push OPEN button
1.  In «OUTPUT Buffer» > «CONTROL MODE
SETPOINT»
2.  Select [Open] (value = 4)
