Vatech PHT-30CSS - Slice Thickness Evaluation; Slice Thickness Standard; Phantom Specification; Test Method

Vatech A9 (PHT-30CSS)
Technical manual
VDH-TeM-098
110 / 214
COPYRIGHT© 2020 VATECH.
ALL RIGHTS RESERVED
8. Slice Thickness Evaluation
8.1. Slice Thickness Standard
Parameter LSL (Lower Specification Limit) USL (Upper Specification Limit)
Slice Thickness 38.0 mm 42.0 mm
8.2. Phantom Specification
QUART: DVT Phantom
8.3. Test Method
1. Open the CT_DVT Phantom image captured in Section 1.3 through the 3D Viewer
2. Measure the length of the phantom in the Sagittal view.
8.4. Test Result
Parameter LSL Measurement value USL Pass/Fail
Slice Thickness 38.0 mm 42.0 mm
