Vatech A9 (PHT-30CSS)
Technical manual
VDH-TeM-098
15 / 214
COPYRIGHT© 2020 VATECH.
ALL RIGHTS RESERVED
The following boards are mounted on the vertical unit.
MCU028 board
Ethernet Grabber
Power board
Noise Filter
