Indicates the available memory. A prompt will be
displayed in case of insufficient memory.
Indicates the remaining battery capacity.
6.2.1. Photo Capturing
1. There are two methods to take photos.
* Press the photo button on the endoscope
* Tap icon on the screen.
2. When taking photos, the icon turn to . The photo has been taken when the icon
will return to its original state.
3. After taking a photo, the quick preview icon displays the current number of photos after the photo
is added.
Note
Keep the Vathin endoscope as still as possible to prevent obscure images during photo capture.
6.2.2. Video Recording
1. Tap icon to start recording. The icon will turn to ,
will appear in the lower
right corner of the screen to indicate the recording time. Tap icon again to end the video
recording and
will disappear. The video has been taken when "Video saved
successfully" is displayed.
When a single endoscope is attached, a thumbnail image of the captured video is displayed in the
lower left corner of the monitor when the recording is complete. If multiple endoscopes are inserted at
the same time, the center image and the bottom left corner image can be recorded simultaneously
and there is no thumbnail image displayed in the bottom left corner of the display after recording..
6.2.3. Image freezing
Tap icon , the icon will trun to . The center image will be frozen, and zoomed out to the
bottom left corner of the screen for real-time display. Tap icon again to end the freezing operation,
the icon will return to its original state, and the center image will become a real display..
