Fig. 2.7c - Example of charts with Depth graph
Ship's coordinates
Speed Over Ground
Course Over Ground
Used Satellite
COG
(Course Over Ground)
Fix Status
Altitude
Date and time
Tracked, but not
used, Satellite
Bars to indicate
S/N Ratio
(Horizontal dilution of
precision)
Index for position-fixing
accuracy
(Vertical dilution of
precision) Index for
position-fixing accuracy
Fig. 2.6d - Example of GPS page
Fig. 2.7e - Example of Navigation Data
Fig. 2.7f - Example of 3D Navigation Data, if Target is set
