User Manual
AUX IN I/O Cable Wiring page
Shows a window containing the AUX IN I/O cable wiring.
[MENU] + [MENU] + "INPUT/OUTPUT" + [ENTER] + "AUX IN I/O CABLE
WIRING" + [ENTER]
MAP 7w Plus GPS/MAP 7wi Plus GPS/MAP 7cwi Plus GPS:
Quick Disconnect Cable Wiring page
Shows a window containing the cable wiring of the quick disconnect bracket.
[MENU] + [MENU] + "INPUT/OUTPUT" + [ENTER] + "QUICK DISCONNECT
CABLE WIRING" + [ENTER]
MAP 11csE Plus GPS/MAP cX Plus GPS:
Power I/O Cable Wiring page
Shows a window containing the Power I/O cable wiring.
[MENU] + [MENU] + "INPUT/OUTPUT" + [ENTER] + "POWER I/O CABLE
WIRING" + [ENTER]
MAP cX Plus GPS:
GPS Cable Wiring page
Shows a window containing the GPS cable wiring.
[MENU] + [MENU] + "INPUT/OUTPUT" + [ENTER] + "GPS CABLE WIRING"
+ [ENTER]
MAP 11csE Plus GPS:
Engine Cable Wiring page
E
Shows a window containing the engine interface cable wiring.
[MENU] + [MENU] + "INPUT/OUTPUT" + [ENTER] + "ENGINE CABLE WIR-
ING" + [ENTER]
MAP 7w Plus GPS/MAP 7wi Plus GPS/MAP 7cwi Plus GPS:
Video Input
E
By accessing this menu it is possible to see images on the chart plotter display
captured from an external video signal source, if connected to the chart plotter.
Allows the "picture-in-picture" functionality, so a Video Input image can be shown
on a image at full screen.
[MENU] + [MENU] + "INPUT/OUTPUT" + [ENTER] + "VIDEO INPUT" +
[ENTER]
Select Video Input
E
: Available options are the following: Full Video: Shows the image from the video camera at
full screen. PiP (Picture In Picture) Video: Shows the cartographic image at full screen, with
the image from the video camera on a window which can be moved up/down and/or right/
left using the cursor key. None.
Activate Video Input
E
: Activates Video Input from menu. At the activation of the Video Mode the following messages
are shown on a dedicated window: "Connnected Video Input Signal is XXXX. The Video
Mode will be activated". XXXX can be PAL or NTSC: the software automatically detects the
type of Video Input source connected. Once the Video Mode is active use the [LIGHT] and
[CONTRAST] keys to adjust video settings. Pressing any other key exits from Video Mode.
Restore Defaults
E
: Restores default values of Contrast, Brightness, Backlight, color saturation and Hue phase
MAP 11csE PLUS GPS:
Video Input
E
By accessing this menu it is possible to see images on the chart plotter display
captured from an external video signal source, if connected to the chart plotter.
Allows the "picture-in-picture" functionality, so a Video Input image can be shown
on a window and placed over the other Video Input or cartography image at full
screen.
