62
User Manual
and activate the navigation to it.
Any variation to the current C-Link
E
Navigation Data will be transferred from the
Master to the Slave.
The Slave will be provided with a few dedicated pages to show the C-Link
E
Navi-
gation Data received from the Master.
Operations
Introductive elements
It is important remark, once more, that this function does not transfer the whole
route but just the information relative to the navigation. Such information will be
removed from the Slave chart plotter as soon as the navigation is terminated.
C-Link
E
navigation data is exchanged by using two NMEA-0183 C-MAP proprietary
sentences: $PCMPN,1 and $PCMPN,2.
When the navigation is activated on the Master, it starts output the C-Link Naviga-
tion Data. If the Slave is connected, all C-Link
E
Navigation Data received are
stored in its memory and the navigation is started.
The information sent by the Master consists of the following values:
♦ Navigation mode (To Single Destination/to a Route)
♦ Route Name*
♦ Destination ID
♦ Destination Position
♦ Next Waypoint ID*
♦ Range from Destination to next Waypoint*
♦ Bearing from Destination to next Waypoint*
♦ Route Length*
♦ Distance from Destination to Last Route Waypoint*
♦ Remaining Route Legs*
♦ Planned Cruising Speed
♦ Average Fuel Consumption
♦ Initial Fuel Load
C-Link
E
Navigation Data can refer to:
♦ Single Destination navigation
♦ Route Following navigation
Values identified by * are sent only for Route Following navigation.
The Destination Icon, Navigation leg (Fix Position to Destination), the Next Waypoint
Icon and all other relevant C-Link
E
Navigation Data will be shown on the Slave
chart plotter. Any variation of the C-Link
E
Navigation Data on the Master will be
communicated to the Slave so to keep data aligned on both devices.
Master Chart Plotter
Operating mode
To select the Master mode follow the procedure:
[MENU] + [MENU] + "Input/Output" + [ENTER] + "C-Link" +
[ENTER] + "Primary Station" + [ENTER]
Master mode is the default factory setting. All regular chart plotters functions are
allowed. As soon as the Destination is placed, the Master chart plotter will start
transmitting all C-Link
E
Navigation Data.
In Master mode the C-Link
E
Navigation Data received from the NMEA port is ig-
nored. So, if the two chart plotters are both operating in Master mode, the C-Link
E
Navigation Data sent by the other chart plotter never processed.
