54
User Manual
turn from "Off" to "On" for making visible these functions in the chart plotter
menus, and then for using in the chart plotter handling.
4.7 INPUT/OUTPUT
WARNING
After a software upgrade the RAM is cleared and then the chart plotter starts
with the default settings. Then you have to go into the Input/Output menu and
set again the proper input format.
MAP 7wi Plus GPS/MAP 7cwi Plus GPS:
Internal GPS Setup Menu
[MENU] + [MENU] + "INPUT/OUTPUT" + [ENTER] + "INTERNAL GPS SETUP"
+ [ENTER]
Internal GPS : Enables (On) or disables (Off) the Internal GPS.
Restart GPS
E
: Restarts all GPS processes. Once executed, the message "Done" is shown.
Diff Correction Source : Sets what kind of Differential Correction will be used by the GPS between WAAS/EGNOS
and RTCM-104 (beacon correction).
Navigation Speed
E
: Sets the Navigation Speed among 0.1 Kts (low speed, for marine/pedestrian application),
0.9 Kts (medium speed, for marine application) and 3.0 Kts (high speed, for car
application).
MAP 7cwi Plus GPS:
Fish Finder Transmission
The Fish Finder embedded is connected directly to the Port 2. To switch the inter-
nal Fish Finder transmission On/Off follow the procedure:
[MENU] + [MENU] + "INPUT/OUTPUT" + [ENTER] + "FISH FINDER ON/
STANDBY" + [ENTER]
Autopilot Connection
E
Connect the Autopilot to the serial Port n:
[MENU] + [MENU] + "INPUT/OUTPUT" + [ENTER] + "PORT n OUTPUT" +
[ENTER]. Then choose your preferred setting among the NMEA available
settings NMEA 0183 4800-N81-N, NMEA 0180, NMEA 0180/CDX) and press
[ENTER] to confirm.
Where:
n = 1/2/3 for MAP 11csE Plus GPS
n = 1/4/5 for MAP 7cwi Plus GPS
n = 1/2/4/5 for MAP 7wi Plus GPS
n = 1/2/3/4/5 for MAP 7w Plus GPS/MAP CX Plus
External NMEA Connection
E
Connect the External NMEA to the serial Port n:
[MENU] + [MENU] + "INPUT/OUTPUT" + [ENTER] + "PORT n INPUT"
+ [ENTER]. Then choose your preferred setting and press [ENTER] to confirm.
Where:
n = 1/2/3 for MAP 11csE Plus GPS
n = 1/4/5 for MAP 7cwi Plus GPS
n = 1/2/4/5 for MAP 7wi Plus GPS
n = 1/2/3/4/5 for MAP 7w Plus GPS/MAP CX Plus
C-COM GSM PLUS Connection
E
To connect the modem C-COM to the chart plotter follow the procedure:
