Vectronix PLRF10C - Troubleshooting: Distance Gate Display (GATE); Troubleshooting: Azimuth Measurement Symbols

Troubleshooting PLRF10C/15C-2.0en
39
"GAtE" is displayed after
distance measurement
Measured distance is below
selected distance gate
Reduce or turn off the distance
gate (see page 29)
The following symbols are
displayed during azimuth
measurements:
_
_ _
_
_
_ _
_
_
_ _
_
_
_ _
_
The allowed inclination and / or
tilt angle has been exceeded
tilted too far upwards
tilted too far downwards
tilted too far to the right
tilted too far the the left
Stay within specified inclination
and / or tilt angle (see page 9)
Problem Possible cause Solution
