Vectronix PLRF10C User Manual

Troubleshooting PLRF10C/15C-2.0en
40
Inaccurate azimuth values Incorrect declination setting
Disruptive magnetic fields at
measuring position
Bad compensation constants
Altered magnetic conditions
within the instrument
(e.g. battery change)
Set correct declination (see
page 30, 31)
Respect factors affecting
azimuth measurement
accuracy (see page 21)
Perform compass
compensation (see page 33)
Perform compass
compensation (see page 33)
Compass compensation can
not be completed
Timing out of compensation Follow the instructions slightly
faster (see page 34)
The electronic reticle is not
visible
"ErOF" is set in the
configuration menu
Select "ErOn" in the
configuration menu
(see page 24)
Problem Possible cause Solution
