VECTOR ™- USMC VECTOR 21-V.0.3
2
For safe use of the VECTOR, please note the detailed safety
directions included in this manual.
© 2004 Vectronix AG, ® All rights reserved.
VECTOR™
VECTOR™
As its name implies, the
VECTOR measures the polar
vector from your position to the
target object.
Congratulations on purchasing
your VECTOR.
VECTOR = 4 instruments in 1:
• Binoculars
Superb optics in a robust,
watertight, rubber-armoured
casing.
• Digital Compass
Displays magnetic azimuth or
grid azimuth in degrees or
mils.
• Laser Rangefinder
Measures from 5 m to over
10 km (depending on visibility
and nature of target objects).
• Inclinometer
Displays vertical angles
between -45° and +45°.
r Range (slope distance)
a Azimuth (bearing, horizontal
direction, angle between
north and object)
v Vertical angle (inclination,
elevation)
