Vectronix USMC VECTOR 21 User Manual

VECTOR ™- USMC VECTOR 21-V.0.3
42
Settings
Setting the PLGR+96
• Set the tracking mode to CONT.
• Select the position format which corresponds to
the map being used.
• Select the appropriate ELEV units.
• Select the appropriate ELEV reference.
• Select the appropriate ANG units.
• Select the appropriate ANG reference (Grid).
• Select the datum which corresponds to the map
being used.
The proper datum must be selected.
Improper datum selection will result in
poor target position accuracy.
• Set the AUTOMATIC OFF TIMER to OFF.
• Set the SERIAL mode to standard.
Note: Azimuth in VECTOR and Azimuth
on PLGR+96 / PLGR II will be different,
due to Declination Angle.
i
