VECTOR ™- USMC VECTOR 21-V.0.3
Configuration
Carefully slide the night vision
device into the adapter.
Activate the ”niGt” function in
the configuration menu (see
page 28).
Using the VECTOR with a night vision device (continued)
At observation distances below
100 m, focus the night vision
device.
While sighting on an object with
the azimuth botton pressed and
held, adjust PVS-14 (diopter)
eyepiece and (objective) focus
in order to see the object and
azimuth readout clearly.
!
i
Adjust PVS-14 brightness (gain
control) to improve the image.
When you finish using the
night vision device, return
to the normal "niGt OFF" setting.
"niGt on" is displayed,
when function is activated
and used in daylight conditions.
