Sensor Installation Sensor Installation Diagrams
47
Figure 46. Simplified Vacuum Sensor Installation
VS VS VS VS
JB
PRODUCT LINE
TO DISPENSER
VAPOR RETURN
FROM DISPENSER
TO
TLS
STP
vacsensors/fig1.eps
VF VF VF
