17-5
17 Reconciliation Setup Meter Calibration Offset
Meter Calibration Offset
If necessary, press STEP until you see the message:
This feature only appears if BIR is installed. The Meter Calibration offset is added to the dispensed amount
received. The default value is 0.000%. You can enter an offset from -10.000 to +10.000%. Press CHANGE and
enter the desired value (e.g., 0.250%). Press ENTER and the system confirms your choice with the message:
Press STEP to continue.
Modify Tank/Meter Map
If necessary, press STEP until you see the message:
Meter data sent from a POS terminal to a TLS 350R console may be collected from a tank that does not have a
probe. Probes collect height data needed for Business Inventory Reconciliation (BIR). This feature allows you to
assign a meter to a tank that does not have a probe so that BIR can still function.
Note: the system must be configured before you can modify the tank/meter map.
Press ENTER to change the tank/meter map and the system displays:
Press or to move to the field you want to change. Then press CHANGE until the correct choice appears.
Press ENTER to confirm your change. Press PRINT to output a report of the current meter map for reference
before proceeding.
The values you may enter are:
Bus--Power or Communications Bay of the console in which the Dispenser Interface Module (DIM) card is placed.
• 2: Power Bay (MDIMs)
• 3: Communication Bay (BDIMs, EDIMs, or CDIMs)
Slot--Slot in which the DIM card is placed.
• 9 - 16 (where 9 is the bottom slot): Slots on Type 2 bus
• 1 - 3 (where 1 is the left-most slot): Slots on Type 3 bus
Fuel--Fueling position number reported by the POS terminal. This number can range from 0 - 99. There is a
maximum of 36 unique fueling position numbers.
Meter--Meter number reported by POS terminal. This number can range from 0 - 99. There is a maximum of 6
unique meter numbers per fueling position.
Tank--One of the following:
METER CALIBRATION
OFFSET: +0.000
METER CALIBRATION
OFFSET: +0.250
MODIFY TANK/METER MAP
PRESS <ENTER>
BUS SLOT FUEL METER TANK
X
XX XX
XX XX
