24-5
24 Output Relay Setup Assignment Method
REMAINING ALARM GROUPS
Continue to step through all of the available alarm groups, selecting the various alarms from the groups that you
want to assign to the selected relay (R1, R2, etc.). The procedure for bypassing or selecting alarms from each
group and then assigning them to a device in that group is the same as discussed for In-Tank alarms above.
The remaining alarm groups/alarms are shown below. Only installed components will display, so some of the alarm
groups may not appear.
LIQUID SENSOR ALARMS
If necessary, press STEP until you see the message:
Select the Liquid Sensor Alarms (ref. Alarm List in Section 6, Table 6-2).
VAPOR SENSOR ALARMS
If necessary, press STEP until you see the message:
Select the Vapor Sensor Alarms (ref. Alarm List in Section 6, Table 6-2).
EXTERNAL INPUTS ALARMS
If necessary, press STEP until you see the message:
Select the External Inputs Alarm (ref. Alarm List in Section 6, Table 6-2).
LINE LEAK ALARMS (VLLD)
If necessary, press STEP until you see the message:
Select Volumetric Line Leak Alarms (ref. Alarm List in Section 6, Table 6-2).
GROUNDWATER SENSOR ALARMS
If necessary, press STEP until you see the message:
Select Groundwater Sensor Alarms (ref. Alarm List in Section 6, Table 6-2).
R1: (Name)
LIQUID SENSOR ALMS: NO
R1: (Name)
VAPOR SENSOR ALMS: NO
R1: (Name)
EXTERNAL INPUTS: NO
R1: (Name)
LINE LEAK ALARMS: NO
R1: (Name)
GROUNDWATER ALMS: NO
