26 Smart Sensor Setup Smart Sensor Label
26-2
Smart Sensor Label
If necessary, press STEP until you see the message:
Enter a name for the sensor connected to the selected Smart Sensor connector. Press CHANGE and enter up to
20 alphanumeric characters. Press ENTER to confirm your entry. The system displays:
Press STEP to continue.
Selecting Sensor Category
If necessary, press STEP until you see the message:
If necessary, press CHANGE until the desired category appears then press ENTER to confirm your choice.
• Air Flow Meter
SMARTSENSOR SETUP
----------------------
s 1:(label)
CATEGORY MAG SENSOR
ALM UPGRADE DELAY: 72
PROGRAMMABLE YES
MIN THRESHOLD 0.0
MAX THRESHOLD 24.0
FUEL ALARM
FUEL HT > 2.0
PROGRAMMABLE NO
UPGRADE NO
WATER WARNING
WATER HT > 2.0
PROGRAMMABLE YES
UPGRADE YES
TEMPERATURE WARNING
FLUID TEMP < -12.5
PROGRAMMABLE YES
UPGRADE NO
Alarm Name
Alarm Parameter
Alarm is programmable (yes/no)
Alarm is upgradeable (yes/no)
Alarm Setup Format
< symbol, i.e., temp warning posted
when temp is less than -12.5 degrees.
Default fluid temp in °F. range is -40 to 120°F
Alarm threshold - default water warn height limit
in inches.
> symbol, i.e., fuel warn posted when height is
greater than 2 inches
device limits - non programmable
For all warnings that are upgradeable, this is the time
(in hours) all uncleared warnings will delay upgrading
to alarms. Range 0 - 9999 hours maximum. Can be
programmed only if the device is factory coded
programmable (in this example yes). If set to 0, the
upgrade option is disabled.
ENTER SMARTSENSOR LABEL
s 1:
s 1: (Name)
PRESS <STEP> TO CONTINUE
s 1: SELECT SS CATEGORY
MAG SENSOR
