Appendix C: Typical Setup Parameters - TLS-350
C-4
*When manifolded tanks are to be configured in order that the system does not give false RECONCILIATION
WARNINGS AND ALARMS, the parameters for reconciliation should be set to 7 LITRES for RECON
WARNINGS and 8 LITRES for RECON ALARMS.
The product code for all partners should be the same, e.g., tank 1 product code 1 manifold partner tank 4 product
code 1.
The calibration update setup parameter must be set to NEVER as systems using a BDIM are theoretically unable
to carry out good calibration. "NEVER" will allow the system to run using only the 1, 4, or 20 point user data input
at time of commissioning.
All of the above setup parameters are required whenever manifolds are to be set if a BDIM is in use.
NOTE: METER DATA should be set to YES – this will allow BIR to run for the manifolded tanks on site.
Leak Min. Annual 0 60%
Periodic Test Type Standard Default
Annual Test fail Al. Disabled Default
Periodic Test Fail Al. Disabled Default
Gross Test Fail Disabled Default
Ann. Test Averaging OFF Default
Per. Test Averaging OFF Default
Tank Test Notify OFF ON
Tank Test Siphon B OFF Default
Recon Warning Limit 3 litres 4 litres*
Recon Alarm Limit 4 litres 5 litres*
Delivery Delay 1 Minute 15 Minutes
Table C-4. Leak Test Method Setup
Parameter Default Set As
Test on Date Current T & D All Tanks Default
Start Time Disabled Default
Test Rate 0.76 LPH Default
Duration 2 Hours 4 Hours
Table C-3. In-tank Setup
Parameter Default Set As
