Veeder-Root TLS-350 - Remove a VMC Serial Number

To Next Page

To Previous Page

27 VMC Setup Remove a VMC Serial Number

27-2

Remove a VMC Serial Number

If necessary, press STEP until you see the message:

Press ENTER. If necessary, press TANK/SENSOR repeatedly until the desired VMC displays.

Press CHANGE.

Press ENTER to confirm..

Press STEP:

Press CHANGE.

Press STEP:

REMOVE VMC SERIAL NUMBER

PRESS <ENTER>

x 1: 111111

REMOVE VMC: NO

x 1: 111111

REMOVE VMC: YES

PRESS <STEP> TO CONTINUE

REMOVE VMC: 111111

ARE YOU SURE? NO

REMOVE VMC: 111111

ARE YOU SURE? YES

REMOVE VMC SERIAL NUMBER

PRESS <ENTER>
