3-1
3 Setup Mode Organization
The Setup Mode is used to enter information and operating parameters that govern the way your system monitors
your installation. Setup data is entered via the front panel keypads. The previous section describes in detail the
functions of each key.
Functions
Functions are the major groups in the Setup Mode of the console.
IMPORTANT! The list below contains all of the available Setup Mode functions. However, only the functions
relevant to your console and its installed options and connected detection systems will be accessible in setup.
• System Setup
• Communications Setup
• In-Tank Setup
• Fuel Management Setup
• In-Tank Leak Test Setup
• Pressure Line Leak Setup
• WPLLD Line Leak Setup
• Line Leak Detector Setup [VLLD]
• Line Leak Test Setup
• Line Leak Lockout Setup
• Pump Sensor Setup
• Pump Relay Monitor Setup
• Reconciliation Setup
• Liquid Sensor Setup
• Vapor Sensor Setup
• Groundwater Sensor Setup
• 2-Wire C.L. Sensor Setup
• 3-Wire C.L. Sensor Setup
• External Input Setup
• Output Relay Setup
• PLLD Line Disable Setup
• WPLLD Line Disable Setup
• Line Disable Setup [VLLD]
• Smart Sensor Setup
• VMC Setup
• Archive Utility
Steps
Within each FUNCTION are STEPS at which you enter setup data.
Setup Mode Programming Table
The table below takes you through the complete setup mode as it appears in the console display with all features
installed (all choices may not appear on your TLS). Always press the ENTER key after entering data. If you press
the STEP, FUNCTION, or MODE key without pressing ENTER, the data will not be saved. It is a good idea to print
