Veeder-Root TLS-350 System Setup Manual

24 Output Relay Setup Setting Up Additional Relays
24-8
Setting Up Additional Relays
After setting up the data for the selected relay (R1, R2, etc.), press STEP, if necessary, until the system returns to
the message:
Press TANK/SENSOR to choose another relay. Set up the relay by repeating the procedures you followed for the
previous relay. Refer to the previous sections beginning with “Relay Designation” on page 24-2. If you have
entered setup data for all relays, press FUNCTION to exit.
ENTER RELAY DESIGNATION
R1:

Veeder-Root TLS-350 Specifications

General

Model	TLS-350
Manufacturer	Veeder-Root
Application	Fuel management
Product Type	Tank gauge
Functionality	Monitors fuel levels
Communication	RS-232
Display	LCD
Environmental Protection	NEMA 4X
