RS-232 Commands Function Code: A10

Function Code: A10

Function Type: Probe Last Sample Buffers Version 1

Command Format:

Display: <SOH>IA10TT

Computer: <SOH>iA10TT

Typical Response Message, Display Format:

<SOH>

IA10TT

TT PP nnnnn

ssss.sss ssss.sss ssss.sss ssss.sss ssss.sss ssss.sss ssss.sss ssss.sss

ssss.sss ssss.sss

<ETX>

Notes:

1. TT - Tank Number (Decimal, 00 = all)

2. PP - Probe Type:03 - MAG1

3. nnnnn - Sample Number (Decimal)

4. ssss.sss - Probe Data (Decimal)

Typical Response Message, Computer Format:

<SOH>iA10TT0000000000TT0PPSSSSNNFFFFFFFF...

TT0PPSSSSNNFFFFFFFF...&&CCCC<ETX>

Notes:

1. 0000000000 - Not Used

2. TT - Tank Number (Decimal, 00 = all)

3. 0 - Not used

4. PP - Probe Type: 03 - MAG1

5. SSSS - Sample Number (Hex)

6. NN - Number of eight character Data Fields to follow (Hex)

7. FFFFFFFF - Probe Data (ASCII Hex IEEE float)

8. && - Data Termination Flag

9. CCCC - Message Checksum

Veeder-Root TLS-HLD User Manual
