55
Console Specifications
PHYSICAL SPECIFICATIONS
•
Width (door closed): 7.6”, open 9.6”) Depth (door closed 2.6”, open 9”))
• Height: 6.7” Weight: 3.5 lbs.
• Two PC boards in console: CPU (in door) and Power Supply (in unit)
ENVIRONMENTAL SPECIFICATIONS
•
Console storage and operation: indoor, climate controlled.
ELECTRICAL SPECIFICATIONS
•
Console operating voltage: 120/240 Vac, 2 A max.
• The Power Supply board fuses F1 and F2 are NOT field replaceable The rating for both fuses is 2 A, Type T [Time
Lag].
SIGNAL INPUT SPECIFICATIONS
•
Up to 6 probes monitored with TLS-HLD
• Probe data: 0.15 A at 12 volts
SIGNAL OUTPUT SPECIFICATIONS
•
One dry contact relay output: 120 Vac, 2 A
FRONT PANEL USER INTERFACE
•
Two line, graphic LCD display
• Visible annunciator (bi-color LED)
Green - all functions normal
Flashing red - alarm active
• Push keys
Select
Enter
Print
Back
Silence
Tank
• Audible annunciator: internal beeper
