Vega VEGAPULS 63 - 4 Mounting Configurations; Configuration Surge Pipe

22
4 Mounting
VEGAPULS 63 • Modbus and Levelmaster protocol
41364-EN-170711
100%
1
2
3
4
5
6
8
9
10
7
15°
45°
0%
Fig.13:CongurationsurgepipeVEGAPULS63
1 Radar sensor
2 Polarisation marking
3 Threadorangeontheinstrument
4 Vent hole
5 Holes
6 WeldingconnectionthroughU-prole
7 Ball valve with complete opening
8 Surge pipe end
9 Reectorsheet
10 Fastening of the surge pipe
Congurationsurgepipe
