Vendo VUE 40 User Manual

C-9
04/2006
POWER DISTRIBUTION ASSEMBLY, 230V
FOR A COMPLETE LIST OF HARNESSES, PLEASE SEE PAGE C-10.
ITEM NO DESCRIPTION QTY PART NO
1 POWER DISTRIBUTION ASSEMBLY, 230V 1 1128002
2 PANEL, POWER DISTRIBUTION 1 1128056
3 FAN 1 1127890
POWER SUPPLY ASSEMBLY 1 1128111
4 POWER SUPPLY COVER 1 1127365
5 POWER SUPPLY, 24 VOLT DC 1 1127299
6 POWER SUPPLY PLATE ASSY 1 1128110
7 SCREW, 6-35X.25 TRUSS HEAD 4 V802243
8 RELAY, 24 VOLT DC 3 1125525
9 TRANSFORMER, INTERNATIONAL, 24 VAC 1 1121932
10 FUSE HOLDER (1¼ “ X 1/4”) 1 1128474
11 FUSE, 0.8A/250V, 3AG SLO-BLOW 1 1053864
12 FUSE HOLDER (5mm X 20 mm) 1 1128473
13 FUSE, 3.15 AMP SLOW BLOW 1 1127484
14 SCREW, 10-16 X 1/2” HEX HEAD 4 V801422
15 SCREW, 10-16 X 5/16” HEX HEAD 16 V801421
16 BUSHING 4 1116634
17 HARNESS, POWER DISTRIBUTION, HIGH VOLTAGE (NOT SHOWN) 1 1128054
18 HARNESS, POWER DISTRIBUTION, LOW VOLTAGE (NOT SHOWN) 1 1128055
19 BOX, DISTRIBUTION PANEL 1 1128051
20 ELECTRONIC BALLAST ASSEMBLY 1 1127556
21
CORDSET, UK (NOT SHOWN) 1 1121642
CORDSET,CONT EUROPE (NOT SHOWN) 1 1121641
CORDSET, AUSTRALIA (NOT SHOWN) 1 1121643
