Vendo VUE 40 User Manual

ST-4
04/2006
TRAY ASSEMBLY
* NOTE: WHEN ORDERING PRICE LABELS AND PRODUCT I.D. LABELS, PLEASE PROVIDE 9-CODE
AND STYLE.
ITEM DESCRIPTION QTY. PART NO.
1 TRAY ASSEMBLY 1 1125204
2 TRAY BODY ASSEMBLY 1 1128180
3 TRAY FRONT 1 1125142
4 PRODUCT SLIDER, TRAY 2 1125141
5 SCREW #8-10 X 1/2” PAN HEAD 4 V802214
6 PUSHER, TRAY ASSY 2 1125140
7 GATE, LEFT, TRAY ASSY 1 1128285
8 PIN, PIVOT, TRAY FRONT 2 1125192
9 GATE, RIGHT, TRAY ASSY 1 1128284
10 SPRING, PUSHER, TRAY ASSY 2 1125526
11 GATE, CENTER, TRAY ASSY 1 1125737
12 ROLLER, SPRING 2 1125821
13 SPRING, TORSION, LEFT 1 1125856
14 SPRING, TORSION, RIGHT 1 1125856-1
15 SPRING, TENSION 1 1060023
16 REFLECTOR, TRAY ASSY 1 1126341
17 PRODUCT NUMBER LABEL 1 1127640
18 PRICE LABELS A/R *
19 PRODUCT I.D. LABELS A/R *
20 STOP ROD 1 1126342
