Vendo VUE 40 User Manual

D-21
05/2006
DELIVERY HOPPER AND FLAP ASSEMBLY
ITEM NO DESCRIPTION QTY PART NO
1 DELIVERY BUCKET ASSEMBLY (SEE D22-D23) 1 1126166
2 COVER PLATE, DELIVERY BUCKET 1 1127249
3 ELECTRIC DOOR SWITCH 1 323007
4 NUT, 3/8-32 X 3/32 HEX 1 V801449
5 SCREW, #10 -16 X 3/8 B CR HEX STL 2 V802047
6 PCBA, HOPPER ILLUMINATION LEDS 1 1126506
7 1/4 NYLON STANDOFF 2 1121740
8 ASSEMBLY, DELIVERY FLAP MOTOR 1 1128274
9 BRKT, DELIVERY FLAP MOTOR MTG 1 1128235
10 SCREW, #10-16 X 5/16 B CR HEX TAP 1 V801421
11 GEAR MOTOR, DELIVERY FLAP 1 1128053
12 SCREW, #8 X 7/8 CR PAN HD 4 V802180
13 CRANK, DELIVERY FLAP MOTOR 1 1128233
14 DELIVERY BUCKET MOTOR 1 1125709
15 BARRIER PANEL, BUCKET MOTOR 1 1128339
16 RETAINER, OUTER FLAP 1 1125891
17 FLAP ASSEMBLY, PRODUCT DELIVERY 1 1128272
18 FLAP, PRODUCT DELIVERY 1 1125871
19 LEVER ARM, DELIVERY FLAP 2 1125873
20 INNER FLAP, PRODUCT DELIVERY 1 1128236
21 PIVOT PIN, INNER FLAP, GFV 1 1128410
22 1/4 E SPG-STL RETAINER RINGS 1 V801077
23 SPRING 1 1126510
24 DRIVE LINK, DELIVERY FLAP 1 1128234
25 SCREW, #8-10X1/2 CR PN THRD CUT 25 ZI 5 V802214
26 WASHER #10 STL PLAIN 1 V801013
27 BRACKET, INNER FLAP RETAINER 1 1128250
28 SCREW, #10-16 X 5/16 B CR HEX TAP 2 V801421
