Vendo VUE 40 User Manual

D-7
05/2006
HAND ASSEMBLY
ITEM NO DESCRIPTION QTY PART NO
1 Z HOUSING/HAND ASSEMBLY 1 1127445
2 Z HOUSING ASSEMBLY 1 1125084
3 HAND ASSEMBLY 1 1127404
4 SPRING, DRIVER ASSIST 1 1127303
5 ROLLER GUIDE REPLACEMENT KIT 1 1128060
6 ROLLER GUIDE 1 1125068
7 NYLOCK NUT - 6mm 1 V802235
8 CLAMP MOTOR REPLACEMENT KIT 1 1128061
9 MOTOR, CLAMP AXIS 1 1127440
10 SCREW - 3mm X 12mm - CR FLAT HEAD 2 V802254
11 Z MOTOR REPLACEMENT KIT 1 1128062
12 X-Z DRIVE MOTOR 1 1124015
13 DRIVE WHEEL - Z AXIS 2 1123967
14 FINGER PAD REPLACEMENT KIT 1 1128063
15 GRIPPER - FINGER - GFV 2 1126841
16 PAD - GRIPPER - MID 2 1128369
17 PAD - GRIPPER - UPPER 2 1128368
