Vendo VUE 40 User Manual

D-3
05/2006
DOOR ASSEMBLY
* NOTE: WHEN ORDERING SERVICE DOOR ASSEMBLY, CONTROL PANEL, OR DOOR GUARD,
PLEASE PROVIDE 9-CODE AND MANUFACTURER’S DATE CODE.
ITEM NO DESCRIPTION QTY. PART NO
1 SERVICE DOOR ASSEMBLY ~ *
2 CONTROL PANEL 1 *
3 DOOR GUARD 1 *
4 DOOR ROLLER ASSEMBLY 1 1120564-7
5 T-HANDLE LOCK ASSEMBY (SEE D24) 1 1127407
6 KEYPAD ASSEMBLY (SEE D17) 1 1127321
7 COIN ENTRY & COIN RETURN ASSEMBLY (SEE D18-D19) ~ ~
8 DBV PLUG 1 388216
9 INSULATED GLASS PANEL 1 1125109
10 GLASS RETAINER - TOP & BOTTOM 2 1126250
11 GLASS RETAINER - RIGHT & LEFT 2 1126250-1
12 LATCH SLIDER BAR ASSEMBLY, T-HANDLE LOCK 1 1125550
LATCH SLIDER BAR ASSEMBLY, ELECTRONIC LOCK 1 1125550-1
13 GLIDE, NYLON 5 1126532
