D-5
05/2006
DOOR ASSEMBLY (CONTINUED)
* NOTE: WHEN ORDERING FOAMED DOOR ASSEMBLY PLEASE PROVIDE 9-CODE AND
MANUFACTURER’S DATE CODE.
ITEM NO DESCRIPTION QTY. PART NO
1 FOAMED OUTER DOOR 1 *
2 Z-HOUSING & HAND ASSEMLBIES (SEE PG D8) 1 ~
3
Y-RAIL ASSEMBLY-HINGE SIDE (SEE PGS D9 - D10) 1 1128143
Y-RAIL ASSEMBLY-LATCH SIDE (SEE PGS D11 - D12) 1 1128144
4 X-RAIL & X-CARRIAGE ASSEMBLIES (SEE PGS D13 - D16) 1 ~
5 DELIVERY ASSEMBLY (SEE PGS D20-23) 1 ~
6 COIN ENTRY & COIN RETURN ASSEMBLY (SEE PGS D18 - D19) 1 ~
7 COIN BOX 1 1128808
8 COIN BOX SHELF 1 1125511
9 COINAGE MOUNTING BRACKET 1 1128574
10 COINAGE SLIDE LATCH 1 1127225
11 COINAGE GUIDE MOUNTING BRACKET 2 1126794
12 CABLE GUIDE BRACKET 1 1128759
13 COVER, HARNESS LOOP 1 1126775
14 CHUTE, COINBOX 1 1127248
~ CONTROL BOARD ASSEMBLY 1 1126512
15 CONTROL BOARD MOUNTING BRACKET 1 1125533
16 STANDOFF 7 1121740
17 PCBA - VEC 15.1 1 1128085
18 PCBA COVER 1 1123529
19
LOWER INSULATED PANEL ASSEMBLY-NO CUT OUT, 41.5" 1 1126059
LOWER INSULATED PANEL ASSEMBLY-NO CUT OUT, 34" 1 1126055
LOWER INSULATED PANEL ASSEMBLY-WITH CUT OUT, 41.5" 1 1128015
LOWER INSULATED PANEL ASSEMBLY-WITH CUT OUT, 34" 1 1128072
20 BRACKET, CONTROL BOARD, COVER 1 1134991
21 SCREW, #10-16 X 1/2 P HEX HD ZP 1 V802141
22 MTG BRKT ASSY, COIN SECURITY 1 1128516
23 SCREW, #10-16 X 1/2 CR HEX SELF DRILL 2 V801489
