Vendo VUE 40 User Manual

D-10
05/2006
Y RAIL ASSEMBLY - LEFT / HINGE SIDE
ITEM NO DESCRIPTION QTY. PART NO
1 Y-RAIL ASSEMBLY, HINGE SIDE 1 1128143
2 EXTRUSION RAIL - Y AXIS - LEFT 1 1128139
3 STRIP - DRIVE TRACK - Y AXIS 1 1128142
4 BRKT - STOP - Y RAIL 1 1127860
5 8-18 7/16 HEX SLOT STL-ZINC 2 V800586
6 SCREW, #10 - 16 X 3/8 2 V802212
7 WSHR .375 O.D. X .170 I.D. 4 V801455
8
Option #1
DRIVE CARRAGE ASSY - Y AXIS - LEFT 1 1127863
8
Option #2
DRIVE CARRAGE ASSY - Y AXIS - LEFT 1 1125079
DRIVE WHEEL - Y AXIS 1 1127330
PAD, Y-AXIS STOP, GFV 1 1127935
