D-12
05/2006
Y RAIL ASSEMBLY - RIGHT / LATCH SIDE
ITEM NO DESCRIPTION QTY PART NO
1 Y RAIL ASSEMBLY, LATCH SIDE 1 1128144
2 EXTRUSION RAIL - Y AXIS - RIGHT 2 1128139
3 STRIP - DRIVE TRACK - Y AXIS 1 1128142
4 8-18 7/16 HEX SLOT STL-ZINC 2 V800586
5 BRKT - STOP - Y RAIL 1 1127860
6 SCREW, #10 - 16 X 3/8 2 V802212
7 WSHR .375 O.D. X .170 I.D. 4 V801455
8
Option #1
DRIVE CARRAGE ASSY - Y AXIS - RIGHT 1 1127862
8
Option #2
DRIVE CARRAGE ASSY - Y AXIS - RIGHT 1 1125080
DRIVE WHEEL - Y AXIS 1 1127330
SPACER,MAGNET,X-HOME 1 1127891
MAGNETIC ACTUATOR-HAMLIN 1 1125941
9 PAD, Y-AXIS STOP, GFV 1 1127935
